Rogers PCB is widely used in the communication industry and network technology fields

Application: Consumer electronics field
Characteristic: Min. width/space: 4/4mil, Aspect ratio:12:1
Material: FR4, 94V-0, RoHS
PCB Layer: 6 Layers
Thickness: 1.6mm
Copper thickness: 1oz - 2oz
Surface finished: Immersion gold (2u")
Solder Mask: Green
IPC Standard: IPC 600 Class 2 & Class 3
Testing: AOI Inspection & 100% E-test

REQUEST A QUOTE

Rogers PCB – Technical specification

Feature	Technical specification
Number of layers	2 ~ 52 layers
Materials	FR4, （ 94V-0, Tg 135, Tg 150, Tg 170 ）
Solder Mask Color	Green, Blue, Black,White, Red, Yellow, Purple, Pink, Grey
Characters	White, Yellow, Black, etc.
Board Thickness	0.2mm - 6.0mm
Copper weights (finished)	0.5oz - 6.0oz
Minimum Trace/Space	0.07mm / 0.07mm
Minimum dimensions	5mm x 5mm;
Maximum dimensions	610mm x 600mm
Minimum mechanical drill (PTH)	0.15mm
Minimum laser drill (blind/micro hole)	0.1mm
Surface finished	HASL - Hot air solder leveling Lead - free HASL - RoHS ENIG - RoHS Immersion Silver - RoHS Immersion Tin - RoHS Golden finger - RoHS OSP - RoHS
E-Testing	100% E-Test , Flying Probe Test & Fixture Test
IPC Standard	IPC 600 Class 2 & Class 3

High Frequency PCB

High-frequency electronics are the trend today, especially in wireless networks.
The rapid growth of satellite communications, the development of information products to high-speed, high-frequency. Therefore, the development of new products always requires the use of high-frequency substrates, satellite systems, mobile phone receiving base stations, etc. These communication products must use high frequency PCBs. A high frequency PCB is a special type of PCB with high electromagnetic frequencies. Generally speaking, a high frequency PCB can be defined as a PCB with a frequency above 1GHz. The substrate material needs to have excellent electrical properties, good chemical stability, and with the increase of the power signal frequency, the loss on the substrate is very small, so the importance of high frequency PCB is highlighted.
High-frequency PCB circuit boards with induction heating technology have been widely used in the communication industry, network technology field promotion and high-speed information processing systems, meeting the requirements of many high-precision parameter instruments. Reliable high-frequency circuit boards provide great help in actual production.
